30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use

30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use
30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use

큰 이미지 :  30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use

제품 상세 정보:
원래 장소: 중국
브랜드 이름: GNEE
인증: SGS
결제 및 배송 조건:
최소 주문 수량: ≥1sets
가격: According to the product
포장 세부 사항: 제품에 따르면
지불 조건: L/C,D/A,D/P,T/T,웨스턴 유니온,MoneyGram
접촉

30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use

설명
제품: VPSA 산소 발생기 온도: 주변환경
수명: +10 년 예어: VPSA 산소 공장
무게: 능력에 의존하세요 압력 등급: 고압
유지: 유지 보수 요구 사항이 낮습니다 청정: 90%-94%
제어 시스템: 터치스크린을 갖춘 PLC 적용산업: 제조 공장, 에너지 및 광업
공기 압축기 전력: 22-110KW 대기 이슬점: ≤℃60 0
작동 온도: 5-45 ° C 바닥면적: 작은
강조하다:

93% Purity VPSA Oxygen Generator

,

30 Nm³/h VPSA Oxygen Plant

,

Low Maintenance Industrial Oxygen Generator

30 Nm³/h 93% Purity VPSA Oxygen Generator for Chemical Production
The VPSA process operates similarly to PSA technology, with the key difference being adsorption at atmospheric or slightly above atmospheric pressure (0-50Kpa) and desorption using vacuum pumps (-50 to -80Kpa). While VPSA systems involve more complex equipment and higher initial investment compared to PSA, they offer significantly lower power consumption, making them ideal for large-scale oxygen production applications.
Key Features & Benefits
  • User-friendly complete system featuring Siemens SIMATIC® PLC control system, Siemens Graphical Touch Panel HMI, and standard Profinet Industrial Ethernet Interface
  • Comprehensive safety features with proven operational savings
  • Guaranteed oxygen purity with continuous 24/7 O2 analysis
  • Adsorber vessels compliant with 2014/68/UE standards
  • Eliminates supply chain failures with continuous production capability
  • Eco-friendly solution with zero pollutant emissions
Main Technical Parameters: 80% Purity VPSA Oxygen Production
Model Specification VPSA-500 VPSA-1000 VPSA-2000 VPSA-3000 VPSA-4500 VPSA-6250 VPSA-7500
Gas Production Nm³/h 500 1000 2000 3000 4500 6250 7500
Voltage 10kv 10kv 10kv 10kv 10kv 10kv 10kv
Installed Power KW 250 435 715 1120 1600 2240 2500
Valve Gas Consumption m³/min 1.0 1.5 2.0 3.0 5.0 6.0 6.5
Cooling Water Circulation m³/h 20 40 80 110 120 130 140
Soft Water Consumption m³/h 1.92 2.7 2.88 3.9 4.2 4.5 4.8
Main Technical Parameters: 93% Purity VPSA Oxygen Production
Model Specification VPSA-200 VPSA-300 VPSA-400 VPSA-500 VPSA-600 VPSA-800 VPSA-1000
Gas Production Nm³/h 200 300 400 500 600 800 1000
Voltage 380v 380v 380v 380v 380v 10kv 10kv
Installed Power KW 120 165 200 270 317 380 450
Valve Gas Consumption m³/min 0.5 0.7 0.9 1.1 1.4 1.6 2.0
Cooling Water Circulation m³/h 11 15 20 26 30 38 55
Soft Water Consumption m³/h 1.2 1.8 1.98 2.1 2.1 2.4 2.7
Main Technical Parameters: 93% Purity VPSA Oxygen Production (Extended Range)
Model Specification VPS-1200 VPS-1600 VPS-2000 VPS-3000 VPS-3600 VPS-4500 VPS-5500
Gas Production Nm³/h 1200 1600 2000 3000 3600 4500 5500
Voltage 10kv 10kv 10kv 10kv 10kv 10kv 10kv
Installed Power KW 565 715 1000 1250 1600 2000 2500
Valve Gas Consumption m³/min 2.0 2.4 3.0 3.3 4.2 5.5 6.5
Cooling Water Circulation m³/h 62 90 100 110 120 130 140
Soft Water Consumption m³/h 2.7 2.88 3.3 3.6 4.2 4.5 4.8
30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 0 30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 1 30 Nm³/h 93% Purity VPSA Oxygen Generator with Low Maintenance for Industrial Use 2
How Does a VPSA Oxygen Generator Work?
VPSA technology represents one of the leading solutions in oxygen generation, offering exceptional energy efficiency and reliability. The system utilizes a molecular sieve called zeolite to extract oxygen at lower operating pressures. By leveraging vacuum pressures—creating a differential between atmospheric pressure and the absolute pressure generated by the vacuum blower—VPSA systems effectively separate oxygen from nitrogen and other atmospheric elements.
Advantages of VPSA-Based Oxygen Generator Systems
As an on-site oxygen generation solution, VPSA systems typically pay for themselves within one year through significant energy savings. These generators are renowned for their reliability and robust construction, with reduced downtime compared to alternative technologies. The systems are user-friendly, featuring straightforward installation and relocation capabilities.
  • Instant startup with high efficiency in meeting oxygen flow requirements
  • Independent on-site oxygen supply eliminates dependency on third-party suppliers
  • Fully automated operation with remote monitoring, control, and communication capabilities
  • Consistent oxygen purity of 93%
  • Compact, space-efficient design for easy installation
  • Eliminates oxygen transportation needs with continuous on-demand operation
  • Enhanced workplace safety for employees
  • Capacity range from one metric ton to 100 tons per day
  • Low maintenance requirements and operating costs
  • Adjustable pressure and purity settings to meet specific application requirements
  • Lower operating costs compared to PSA oxygen generators
Applications of VPSA Oxygen Generators
  • Chemical manufacturing
  • Gold mining operations
  • Fish hatching and farming
  • Aquaculture systems
  • Wastewater treatment facilities
  • Brazing processes
  • Ethanol production
  • Ozone generation
  • Sewage treatment plants
  • Biogas production
  • Glass furnace operations
  • Mining and smelting facilities
  • Centralized oxygen supply for hospitals and veterinary clinics
  • Room oxygen enrichment systems
